Arduino Mega 2560 Rev3

The Arduino Mega 2560 is a robust microcontroller board based on the ATmega2560, designed for complex and large-scale projects. It features 54 digital I/O pins (15 PWM), 16 analog inputs, and multiple communication options, including 4 UARTs, I2C, and SPI. With 256 KB of flash memory, 8 KB of SRAM, and 4 KB of EEPROM, it can handle memory-intensive applications. Operating at 16 MHz, it is powered via USB or an external power source (7–12V recommended). Its versatility makes it ideal for robotics, IoT, data logging, and automation projects, supported by extensive libraries and community resources.

₹3,304.00

Inclusive of all taxes · GST Invoice available

In stock - 100 unitsFree shipping over ₹500

Delivery Option

Enter your pincode for a delivery estimate

The Arduino Mega 2560 is a robust microcontroller board based on the ATmega2560, designed for complex and large-scale projects. It features 54 digital I/O pins (15 PWM), 16 analog inputs, and multiple communication options, including 4 UARTs, I2C, and SPI. With 256 KB of flash memory, 8 KB of SRAM, and 4 KB of EEPROM, it can handle memory-intensive applications. Operating at 16 MHz, it is powered via USB or an external power source (7–12V recommended). Its versatility makes it ideal for robotics, IoT, data logging, and automation projects, supported by extensive libraries and community resources.

Key Features

Microcontroller: ATmega2560: 8-bit microcontroller with 256 KB flash memory, 8 KB SRAM, and 4 KB EEPROM. Clock Speed: Operates at 16 MHz, suitable for most embedded applications. Input/Output Pins: 54 Digital I/O pins, 15 of which can be used as PWM outputs. 16 Analog input pins (10-bit resolution for reading analog sensors). 6 Hardware Interrupt pins for handling real-time events. Communication Interfaces: 4 hardware UARTs (serial communication ports) for connecting multiple serial devices. Supports I2C and SPI protocols for interfacing with sensors, displays, and other peripherals. Power Supply: Can be powered via USB (5V) or an external power supply (7-12V recommended, up to 20V max). Memory: Flash Memory: 256 KB (8 KB reserved for bootloader). SRAM: 8 KB for runtime variables and arrays. EEPROM: 4 KB for storing non-volatile data. Connectivity: Built-in USB port for programming and serial communication with a PC. Compatible with Arduino IDE. Other Features: Reset Button: Easy way to restart the board. ICSP header for programming with an external programmer. 16 MHz crystal oscillator for stable operation. LED indicators for power and communication (TX/RX).
