BeagleBone Black REV C
- The BeagleBone Black Rev C is a powerful, open-source single-board computer designed for embedded development, IoT projects, and educational purposes. It offers a balance of performance, flexibility, and extensive I/O options. Built around the AM3358 ARM Cortex-A8 processor from Texas Instruments, it operates at 1 GHz and includes a PowerVR SGX530 GPU, enabling 3D graphics acceleration.
₹6,304.00
Inclusive of all taxes · GST Invoice available
In stock - 100 unitsFree shipping over ₹500
Delivery Option
Enter your pincode for a delivery estimate
- The BeagleBone Black Rev C is a powerful, open-source single-board computer designed for embedded development, IoT projects, and educational purposes. It offers a balance of performance, flexibility, and extensive I/O options. Built around the AM3358 ARM Cortex-A8 processor from Texas Instruments, it operates at 1 GHz and includes a PowerVR SGX530 GPU, enabling 3D graphics acceleration.
Key Features
- Processor and Memory: Processor: 1 GHz ARM Cortex-A8. RAM: 512 MB DDR3L. Storage: Built-in 4 GB eMMC flash memory (preloaded with Debian Linux) and a microSD card slot for additional storage. Connectivity: Ethernet (10/100 Mbps) for network communication. USB Host port and USB OTG port for connecting peripherals. No built-in WiFi or Bluetooth (can be added via USB adapters). I/O and Expandability: GPIO Pins: 2 x 46-pin headers (total 92 pins), supporting GPIO, I2C, SPI, UART, and PWM. Analog Inputs: 7 12-bit ADC channels for analog signal reading. HDMI Output: Micro-HDMI for video and audio output, supporting resolutions up to 1920x1080. Expansion: Compatible with various "capes" (expansion boards) to add additional features like motor drivers, LCD displays, and more. Operating System: Preloaded with Debian Linux (runs other distributions like Ubuntu, Android, and Yocto). Supports cloud-based programming and debugging via BeagleBone Cloud9 IDE. Power Supply: Powered via a 5V barrel jack or micro-USB. Low power consumption (~2-3W under normal load). Graphics and Multimedia: Integrated PowerVR SGX530 GPU for rendering 3D graphics. HDMI output for multimedia applications.
